New Products
DOL - 16 Dolphin Plastic Impact Sprinkler - Full Circle
DOL - 16 Dolphin Plastic Impact Sprinkler - Full CircleThis low discharge, low pressure but more coverage than any medium range traditional metal Impact sprinkler, is suitable for versatile use in Agriculture, Horticulture, Plantation, and medium and large scale landscaped areas, This sprinkler shows good performance in windy conditions owing to its low trajectory angle. Unlike old metal impact sprinklers, DOL-16 droplets are very small and does not damage the leafs and other tender parts of even small plants, This won't roughen the surface operated even at its maximum working pressure. Usage of DOL-16 in professionally designed irrigation system ensures irrigation of double the area with the same pump head and discharge at minimum 25% reduced cost. This unique feature of this sprinkler makler makes it farmer friendly for most of the vegetable crops, all kinds of plantation crops, and agricultural crops irrigation.

FEATURES AND SPECIFICATIONS:
Full Circle Plastic Impact Sprinkler available at 26o trajectory angle.Delrin plastic body for added strength.Hardened and Tempered Stainless Steel spring for long life and durability.Well- balanced heavy-duty plastic swing arm to provide correct jet dispersion.Poly acetol nozzles with hydrodynamic inner profile for precise jet and large radius coverage.Easy to install and maintain. ¾" BSP male threaded inlet.Operating pressure range : 1 kgf/cm2 - 2.5 kgf/cm2Available in double nozzle (main and spreader nozzle)

APPLICATIONS
Suitable for all kind of field crops like Ragi, Jowar, Wheat, Gram, Pulses, Cotton, Oil seeds, Fodder grass and etc., all types of vegetables except Tomato, all plantation crops like coconut, Areca, Cocoa, Mulberry, Tea, Coffee, Rubber, etc., Turf areas, home gardens, Parks, Hotels, Resorts Etc.,

PERFORMANCE DATA - DOL-16
PRESSURE COVERAGE(DIAMETER)  DISCHARGE(LPH)  C.D.U. %(By Overlapping)
spacing 18x18 Mtr
1.0 kgf/cm2 50 Feet 1000 100%
1.5 kgf/cm2 60 Feet 1300
2.0 kgf/cm2 70 Feet 1500
2.5 kgf/cm2 80 Feet 1750
Top
DOL - 13 Plastic impact sprinkler 1/2" male

APPLICATIONS
Irrigation of vegetables, flowers and nursery crops, gingers.
FEATURES AND SPECIFICATIONS:
High Water distribution with spacing up to 14 m.
DOL - 13 Plastic impact sprinkler 1/2" male
Color- coded bayonet nozzles for easy service.Integrated stream - straightening vane for maxi-mum range.Suitable to PVC pipes, LLDP (lateral) pipes, clapet valves land QRC. High- impact, heavy- duty plastic materials provide resistance to corrosion, chemicals and UV radiation.

PERFORMANCE DATA - DOL-13
NOZZLE (mm) P (bar) Q (m3/h) D (m) 10x10 10x12 12x112 12x14 14x14
3.0x1.8 2.5 0.760   22.0  7.6 6.3 5.3 4.5 3.9
  3.0 0.840 23.0 8.4 7.0 5.8 5.0 4.3
  3.5 0.900 23.0 9.0 7.5 6.3 5.4 4.6
  4.0 0.970 23.0 9.7 8.1 6.7 5.8 4.9
